10Gbps APD跨阻放大器,8kΩ跨阻增益,低频截止频率6kHz,在电源3.3V下功耗90mW。
10Gbps TIA with AGC designed for APD, 8kΩ transimpedance gain, -3dB low frequency cut-off: 6kHz,90mW power consumption under 3.3V power supply.
10G PON ONU 对称/非对称光收发一体芯片,平均功率和消光比控制,带有兼容SFF-8472数字诊断监视,LDD最高输出调制/偏置电流为90mA/110mA,LA输入灵敏度为5mVppd,1~12.5Gbps速率,具有连续/突发两种模式。
10Gbps PON ONU symmetrical/asymmetric transceiver,Integrated closed-loop Automatic Power Control (APC),compliant with SFF8472 digital diagnostics monitoring(DDM),LDD maximum bias/modulation are 90mA /110mA,LA sensitivity is 5mVppd,1~12.5Gbps Multi-Rate,
Switchable burst and continuation mode
1~14Gbps跨阻放大器,典型-17dBm灵敏度,具有良好的速率兼容性和高灵敏度。
Optical TIA with AGC for1~14Gbps, Typical optical sensitivity is -17dBm with good bandwidth compatibility and high sensitivity.
8.5~28 Gbps PIN TIA,在25.78Gbps速率下灵敏度为-14.5dBm,跨阻增益为5.4kΩ,在3.3V电源下功耗为83mW。
25Gbps PIN Transimpedance Amplifier,Typical -14.5dBm sensitivity@25.78Gbps,Data rate from 8.5 to 28Gbps,
5.4kΩ typical differential transimpedance,83mW power consumption under 3.3V power supply.
一款高性能的56Gbaud线性跨阻放大器( TIA ),设计用于PAM4调制的100Gbps以太网。该器件具有群延迟小、稳定性好、增益高等优点。
High - performance 56Gbaud linear type Transimpedance amplifier ( TIA ), designed for 100Gbps Ethernet operation using PAM4 modulation . The device has been optimized for low group delay variation and good stability with high gain .
四通道28Gbps TIA,-14.5dBm输入灵敏度,信号速率8.5~28Gbps,
5.4kΩ跨阻增益,在3.3V电源电压下功耗335mW。4 Channel-28Gbps TIA, -14.5dBm optical sensitivity,Data rate from 8.5 to 28Gbps,5.4kΩ typical differential transimpedance,
335mW power consumption under 3.3V power supply.
10G LR Transceiver 最大偏置电流120mA,最大调制电流92mApp,集成自动功率控制环路,可编程 TX眼图调整和输入均衡器,上升下降时间可编程; RX输入灵敏度5mVppd(14Gbps),LOS阈值可调整,RX输出摆幅可编程。
Maximum bias current = 120mA;Maximum modulation current into 15Ω differential TOSA = 92mApp,Integrated closed-loop Automatic Power Control (APC),
Programmable TX eye shaping features and input equalization,Programmable rise/fall times,RX sensitivity at14Gbps = 5mVppd,Adjustable loss of signal detect threshold,
Programmable RX output swing.
最大偏置电流15mA,最大调制电流20mApp,RX输入灵敏度5mVppd(14Gbps),RX输出预加重和静噪,LOS阈值可调整。
Maximum bias current = 15mA,Maximum modulation current into 50Ω differential TOSA = 20mApp,
Laser safety features,Rx sensitivity at 14Gbps = 5mVppd,RX output pre-emphasis and squelch,Adjustable loss of signal detect threshold.
8.5 ~28 Gbps APD TIA,在高速模式下的等效输入噪声为1.05uA,信号速率8.5~28Gbps,跨阻增益为5.4kΩ,在3.3V电源电压下功耗为83mW。
28Gbps APD Transimpedance Amplifier,Typical 1.05uA noise in high rate mode,Data rate from 8.5 to 28Gbps,5.4kΩ typical differential transimpedance,
83mW power consumption under 3.3V power supply.
8.5~28 Gbps PIN TIA,在25.78Gbps速率下灵敏度为-14.5dBm,跨阻增益为5.4kΩ,在3.3V电源下功耗为83mW。
25Gbps PIN Transimpedance Amplifier,Typical -14.5dBm sensitivity@25.78Gbps,Data rate from 8.5 to 28Gbps,
5.4kΩ typical differential transimpedance,83mW power consumption under 3.3V power supply.
10G PON ONU 对称/非对称光收发一体芯片,平均功率和消光比控制,带有兼容SFF-8472数字诊断监视,LDD最高输出调制/偏置电流为90mA/110mA,LA输入灵敏度为5mVppd,1~12.5Gbps速率,具有连续/突发两种模式。
10Gbps PON ONU symmetrical/asymmetric transceiver,Integrated closed-loop Automatic Power Control (APC),compliant with SFF8472 digital diagnostics monitoring(DDM),LDD maximum bias/modulation are 90mA /110mA,LA sensitivity is 5mVppd,1~12.5Gbps Multi-Rate,
Switchable burst and continuation mode
0G LR Transceiver 最大偏置电流120mA,最大调制电流92mApp,集成自动功率控制环路,可编程 TX眼图调整和输入均衡器,上升下降时间可编程; RX输入灵敏度5mVppd(14Gbps),LOS阈值可调整,RX输出摆幅可编程。
Maximum bias current = 120mA;Maximum modulation current into 15Ω differential TOSA = 92mApp,Integrated closed-loop Automatic Power Control (APC),
Programmable TX eye shaping features and input equalization,Programmable rise/fall times,RX sensitivity at14Gbps = 5mVppd,Adjustable loss of signal detect threshold,
Programmable RX output swing.
一款宽频带、快速过载恢复、强转换速率、超低噪声和超低谐波失真跨阻放大器,用于光电二极管监控应用。多反馈电阻,简化了高性能光学系统的设计。适用于OTDR系统。
A wideband, fast overdrive recovery, strong slew rate, ultralow-noise and ultralow-HD transimpedance amplifier targeted at photodiode monitoring applications. Multiple-feedback resistance, the EOC1202 simplifies the design of high-performance optical systems which is fit for OTDR system.
一 款输出60V, 内 置 1 . 0A、 内阻0 .6Ω开关的升压转换器,670KHz 开关频率,具有快速电流保护、欠压锁定和过压保护、热保护等功能。可用于激光雷达发射及接收高压电路
Monolithic step up converter integrating a 1.0A,0.6Ω internal switch.Current mode,fixed frequency archi-tecture,providing fast transient response and cycle by cycle current limit.Includes under-voltage lockout,over voltage protection and thermal overload protection.Includes under-voltage lockout,over voltage protection and thermal overload protection preventing damagein the event of an output overload .
是一款宽带、快速恢复、高摆率、具有超低噪声和超低失真的跨导放大器 (TIA) 。 多种反馈电阻选择,适用于激光雷达等高性能要求光学系统设计要求。
EOC1070Q is a wideband,fast overdrive recovery,strong slew rate,ultralow-noise and ultralow-HD tran-simpedance amplifier.Multiple feedback resistance options for high performance requirements such as LiDAR optical system design requiremen
